Siemens SINAMICS G120 CU240E-2 PN 6SL3244 0BB12 1FA0 (Pre-Owned)

Description

SINAMICS G120 CU240E-2 PN 6SL3244 0BB12 1FA0

A pre-owned SINAMICS G120 CU240E-2 PN (6SL3244-0BB12-1FA0)

Pulled from a panel, working according to specification.

In excellent condition.

Features:

• Communication Interfaces: PROFINET and EtherNet/IP
• Operating Voltage: 24 V DC (via Power Module)
• External Power Supply: 20–29 V DC
• Maximum Power Consumption: 0.50 A
• Power Loss: 5.50 W
• Digital Inputs: 6 standard digital inputs
• Digital Outputs: 2 relay changeover outputs
• Analog Inputs: 2 differential inputs
• Analog Outputs: 2 non-isolated outputs
• Supported Control Modes:
  • V/f linear control
  • V/f square-law control
  • Parameterizable V/f control
  • V/f with Flux Current Control (FCC)
  • V/f ECO linear and square-law control
  • Sensorless Vector Control (SLVC)
  • Encoderless Torque Control
• Operating Temperature: -10 °C to +55 °C
• Storage Temperature: -40 °C to +70 °C
• Maximum Relative Humidity: 95%
• Signal Cable Size: 0.05–1.50 mm² (AWG 28–16)
• Ingress Protection (IP Rating):  IP20

Documents

• Datasheet
• Dimension Drawing
• Wiring Diagram (Schematic)

For full specifications, view the official Siemens documentation.
